Hammond Power
CRX0077AC
Line Reactor, Three Phase, 77 Amp, 60hp, 480V, 60Hz, 3% Impedance, 0.29mH Inductance, 105 Watts Loss, Open Core and Coil, Terminal Block
$438.77$438.77 -
Hammond Power
CRX0414AC
Line Reactor, Three Phase, 414 Amp, 350hp, 480V, 60Hz, 3% Impedance, 0.06mH Inductance, 400 Watts Loss, Open Core and Coil, Terminal Block
$1,479.65$1,479.65 -
Hammond Power
CRX0075DC
Line Reactor, Three Phase, 75 Amp, 25hp, 240V, 60Hz, 5% Impedance, 0.285mH Inductance, 105 Watts Loss, Open Core and Coil, Terminal Block
$456.59$456.59 -
Hammond Power
CRX03D9BC
Line Reactor, Three Phase, 3.9 Amp, 3hp, 600V, 60Hz, 5% Impedance, 10.61mH Inductance, 35 Watts Loss, Open Core and Coil, Terminal Block
$129.18$129.18 -
Hammond Power
CRX0075BC
Line Reactor, Three Phase, 75 Amp, 25hp, 240V, 60Hz, 3% Impedance, 0.19mH Inductance, 95 Watts Loss, Open Core and Coil, Terminal Block
$374.92$374.92 -
Hammond Power
CRX03D9AC
Line Reactor, Three Phase, 3.9 Amp, 3hp, 600V, 60Hz, 3% Impedance, 7.058mH Inductance, 22 Watts Loss, Open Core and Coil, Terminal Block
$129.18$129.18 -
Hammond Power
CRX0065BC
Line Reactor, Three Phase, 65 Amp, 50hp, 480V, 60Hz, 5% Impedance, 0.57mH Inductance, 120 Watts Loss, Open Core and Coil, Terminal Block
$511.53$511.53 -
Hammond Power
CRX03D5DC
Line Reactor, Three Phase, 3.5 Amp, 0.75hp, 208V, 60Hz, 5% Impedance, 4.67mH Inductance, 29 Watts Loss, Open Core and Coil, Terminal Block
$136.61$136.61 -
Hammond Power
CRX0065AC
Line Reactor, Three Phase, 65 Amp, 50hp, 480V, 60Hz, 3% Impedance, 0.36mH Inductance, 110 Watts Loss, Open Core and Coil, Terminal Block
$400.17$400.17 -
Hammond Power
CRX0062BC
Line Reactor, Three Phase, 62 Amp, 60hp, 600V, 60Hz, 5% Impedance, 0.742mH Inductance, 170 Watts Loss, Open Core and Coil, Terminal Block
$631.06$631.06 -
Hammond Power
CRX0059DC
Line Reactor, Three Phase, 59 Amp, 20hp, 240V, 60Hz, 5% Impedance, 0.357mH Inductance, 110 Watts Loss, Open Core and Coil, Terminal Block
$423.18$423.18 -
Hammond Power
CRX0055NC
Line Reactor, Three Phase, 55 Amp, 60hp, 690V, 50Hz, 3% Impedance, 0.69mH Inductance, 170 Watts Loss, Open Core and Coil, Terminal Block
$423.18$423.18
Acting as electrical buffers, line and load reactors protect equipment by reducing incoming current surges and harmonic currents.
Line reactors are generally used on the line side of a drive, load reactors are often used with motor circuits on the load side.
