Autonics
ADIO-IL-MA08CAN-HUB3
Remote I/O System, 24VDC, IO-Link Version 1.1, Digital 8 In / 8 Out, 7/8 inch, 5-Pin Power Supply Port, NPN, M12 Connector, 66 x 165 x 32mm (WHD), IP67/IP69K
$449.00
ADIO-IL-MA08CAP-HUB3
Alt: A2300000014
$449.00
Remote I/O System, 24VDC, IO-Link Version 1.1, Digital 8 In / 8 Out, 7/8 inch, 5-Pin Power Supply Port, PNP, M12 Connector, 66 x 165 x 32mm (WHD), IP67/IP69K
- Weight:
- 1.66 LBS
- Minimum Purchase:
- 1 unit
Description
The ADIO Series remote I/O boxes transmit various input and output signals between master devices such as PCs or PLCs and secondary devices including sensors and actuators. The IO-Link master type ADIO-ILM can exchange signals from secondary devices (IO-Link, standard I/O) to industrial networking protocols (EtherCAT, EtherNET/IP, PROFINET).
The NEW IO-Link HUB type ADIO-HUB is connected to ADIO-ILM to expand and relay multiple standard I/O through IO-Link communication.
Specifications
Alternate Part Number
A2300000014
Series
ADIO Series
Product Data Sheet
Autonics ADIO-IL-MA08CAP-HUB3 Datasheet
Full Catalog
Autonics 2023 2024 Full Catalog
Height
6.5"
Weight
1.655
Width
2.6"
Length/Depth
1.26"
Communication Module Type
I/O Modules
Warranty
3 Years
