50117361

Features Include:

• Operating Principle: Reflection principle
• Application: Detection of highly transparent bottles, highly transparent films and glass panes
• Operating Range: 0 - 4 m
• Operating Range Limit: 0 - 4.8 m
• Supply Voltage: 10 - 30 VDC
• Open-Circuit Current: 0 - 18 mA
• Switching Frequency: 1,500 Hz
• Response Time: 0.333 ms
• Dimensions (W x H x L): 15 mm x 47 mm x 32.5 mm
• Housing Material: Metal, Diecast zinc
• Type of Fastening: Through-hole mounting, Front mounting with thread, Via optional mounting device

Need More Information?

• Leuze PRK18B/RK18B Retro-Reflective Sensors for Bottles and Tape Datasheet
• Leuze 18B Series Retro-Reflective Photoelectric Sensor Catalog
