Our Takex AC/DC power photo sensors were developed to make use of your available power. Many of the models are self-switching between AC and DC as well as self-regulating from 24VDC to 240VAC.
The NA Series sensors have relay output and may be used as direct inputs.
Advanced circuitry allows for detection distances up to 30 meters without the use of laser components. AC power is great for many applications; car washes, exposed vehicle detection systems and conveyor detection.
Marshall Wolf Automation is your authorized Takex distributor!
The NA-R10F is diffused reflective type with 0.03 to 7m detection distance and timer function included..
The Timer Function mentioned above has the following selectable options: • Delay-On (Delay time is adjustable from 0.1 to 5 seconds) • Delay-Off • One-Shot • Timer Disabled
Type of PhotoelectricGeneral Purpose Photoelectric
All - Specific RatingsIP66
SeriesNA Series
SizeRectangular
Warranty1 Year
Alternate Part NumberNA Series
Weight.5
Diffused reflective type
0.03 to 7m detection distance
Timer function provided
Light on/Dark on
24 to 240VAC/DC
The Timer Function mentioned above has the following selectable options: • Delay-On (Delay time is adjustable from 0.1 to 5 seconds) • Delay-Off • One-Shot • Timer Disabled
