GSM2RSPN
Takex

GSM2RSPN

Alt: Mini-G Series

$102.34

Photoelectric Sensor, Polarized Reflective, PNP, Red LED, .01 to 2m Range, 12/24VDC, Cable, IP67, Side-On

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Photoelectric Sensor, Polarized Reflective, PNP, Red LED, 2000mm Range, 12/24VDC, Cable

Features Include:

  • Ultra-compact size used for built-in use for over 25 years
  • Various types such as head-on, wide diffuse reflective, high power or convergent reflective
  • M3 threaded screw can be used for all models
  • Water resistance complying with IP67
  • Detection Method: Retroreflective
  • Detection Distance: 0.01-2m (When used with K-71)
  • Detection Object: dia.40mm (or more) Opaque
  • Current Consumption: 25mA or less
  • Power Supply: 12-24V DC ±10% / Ripple 10% or less
  • Operation Mode: Light-ON / Dark-ON selectable (with switch)
  • Operating Angle: 30°(at receiver)
  • Response Time: 0.35ms or less
  • Light source (light wavelength): Red LED (700nm)
  • Volume: SENS: Sensitivity adjustment (on receiver for through-beam type)
  • Switch: Light-ON / Dark-ON selector switch
  • Material: Case: Polyarylate, Lens: Polycarbonate
  • Weight: approx. 50g

Output Mode:

  • Control output: PNP open collector output Rating: source current 100mA (30 VDC) or less
  • Stability output: PNP output type does not have stability output

Indicator:

  • Red LED: Operation indicator
  • Green LED: Stability Indicator

Connection:

  • Cable type (outer diameter: 3mm; length 2m)
  • Transmitter: 0.15mm2 x 2 cores (gray)
  • Receiver: 0.15mm2 x 3 cores (black)

Environmental Specifications:

  • Ambient Light: 5,000 lx or more
  • Ambient Temperature:-25 - +55C (non-freezing)
  • Ambient Humidity: 35 - 85%RH (non-condensing)
  • Vibration: 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
  • Shock: 500 m/s2 / 3 times each in 3 directions
  • Dielectric withstanding: 1,000 VAC for 1 minute
  • Insulation resistance: 500 VDC, 20 MΩ or higher
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Add Selection to Cart
Available Now!

Takex

K-7

Reflector, 60 x 40mm, Acrylic Mirror, Heat Resistant ABS Base, Secured with M3 Screws, for Polarized Retroreflective Models, IP67

$7.18

Takex

K-71

Reflector, Mirror, Acrylic Base, Heat Resistant, ABS, IP67

$8.30
