216896

Features Include:

• Miniature design
• Very bright, highly visible light spot
• Full metal thread mounting
• Clearly visible LEDs for Power ON, switching state and weak signal indication
• Not sensitive to ambient light
• Detection range: 5 - 350 mm
• Reference target: standard white, 100 mm x 100 mm
• Light source: LED
• Light type: modulated visible red light
• Diameter of the light spot: approx. 20 mm at a distance of 350 mm
• Angle of divergence: approx. 4 °
• Operation indicator: LED green: power on
• Function indicator: LED yellow: lights when object is detected
• Control elements: Sensing range adjuster
• Control elements: Light-on/dark-on changeover switch
• Operating voltage: 10 - 30 V DC
• Switching type: The switching type of the sensor is adjustable. The default setting is: light-on
• Signal output: 1 NPN output, short-circuit protected, reverse polarity protected, open collector
• Housing width: 11 mm
• Housing height: 31 mm
• Housing depth: 20 mm
• Degree of protection: IP67
• Connection Connector: M8 x 1 , 4-pin

Technical Information:

• Pepperl+Fuchs ML100-8-H-350-RT/95/102 Datasheet
• Pepperl+Fuchs ML100-8-H-350-RT/95/102 Instruction Manual
• Pepperl+Fuchs ML100 Series Miniature Photoelectric Sensors Brochure
