NE-R10
$107.53
Photoelectric Sensor, Diffuse Reflective, Relay, Infrared LED, AC/DC Power Supply, Connector Type
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Photoelectric Sensor, Diffuse Reflective, Relay, Infrared LED, AC/DC Power Supply, Connector Type
Specifications
Connection
w/Cable
Light Source
LED
NPN or PNP
See Spec or N/A
Light On/Dark On
Dark ON
Sensing Method
Diffuse Reflective
Type of Photoelectric
See Spec or N/A
All - Specific Ratings
IP66
Series
See Specs
Size
See Spec
Warranty
1 Year
Weight
.5
Features Include:
- Detection Method: Polarized retroreflective
- Detection Distance: 0.03-5m (*1)
- Detection Object: Mirror-like, opaque
- Power Consumption: 2 W or less
- Power Supply: AC/DC24-240V ±10% 50/60Hz
- Output Mode: Relay output 1c / Rating: 1 A (250 VAC max. resistance load 30 VDC max. resistance load) (*2) (*3)
- Operation Mode: Dark ON
- Response Time: 5ms or less
- Operating Angle: 30% (at reflector)
- Light source (light wavelength): Red LED (700 nm)
- Volume: Sensitivity adjustment provided
- Material: Lens: acrylic / Case: heat resistant ABS
- Connection: Attached cable (Outer dimension: dia.6mm) 0.3 mm2 x 5 cores, 2 m, black
- Weight: Approx.150g
Indicator:
- Operation indicator (red LED)
- Stability indicator (green LED)
Environmental Specifications:
- Ambient Light: 10,000 lx or less
- Ambient Temperature:-25 - +55°C (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 directions
- Shock: 500 m/s2 / 3 times each in 3 directions
- Dielectric withstanding: 1,500 VAC for 1 minute
- Insulation resistance: 500 VDC, 100 MΩ or higher
