FHDK 10N5101
Baumer

FHDK 10N5101

Alt: 10139965

$379.00

Miniature Diffuse Sensor, Background Suppression, Pulsed Red LED, 20-120mm Range Tw, Mech. 5-Turn Adj., 10-30VDC, Light/Dark Operate, NPN, <100mA, 2m 4-Pin Cable, 27 x 10.4 x 14mm (HWD), Plastic ASA Housing, PMMA Optics, -25 to +65°C, IP65

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Photoelectric Sensor, Diffuse, Background Supp.

Features Include:

  • Type: Background suppression
  • Light source: Pulsed red LED
  • Sensing distance Tw: 20 - 120 mm
  • Sensing range Tb (at Tw max.): 5 - 120 mm
  • Sensing range Tb (at Tw min.): 5 - 20 mm
  • Alignment / soiled lens indicator: Flashing light indicator
  • Light indicator: LED yellow
  • Sensing distance adjustment: Mechanical, 5 turn
  • Distance to focus: 35 - 45 mm
  • Wave length: 660 nm
  • Beam diameter: 4 mm at focus
  • Voltage supply range +Vs: 10 - 30 VDC
  • Current consumption max. (no load): 30 mA
  • Current consumption typ.: 20 mA
  • Voltage drop Vd: < 1.8 VDC
  • Output function: Light/Dark operate
  • Output circuit: NPN
  • Output current: < 100 mA
  • Width / diameter: 10.4 mm
  • Height / length: 27 mm
  • Depth: 14 mm
  • Type: Rectangular
  • Housing material: Plastic (ASA)
  • Front (optics): PMMA
  • Connection types: Cable 4 pin, 2 m
