GR12RSN
$138.84
Photoelectric Sensor, Convergent Reflective, NPN, Color Mark, Red LED, Cable, 12mm Range
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Photoelectric Sensor, Convergent Reflective, NPN, Color Mark, Red LED, Cable, 12mm Range
Features Include:
- IP67 rated housing filled with resin allows washing together with line equipment
- Detection Method: Convergent reflective
- Detection Distance: 12mm ± 2mm
- Power Supply: 12-24V DC±10% / Ripple 10% or less
- Current Consumption: 35mA or less
- Operation Mode: Light-ON / Dark-ON selectable (with switch)
- Anti Interference feature: Available (up to two units)
- Spot Diameter: dia.1mm
- Smallest detectable mark width: 0.5 mm (green mark on white background)
- Connection: Cable type (outer diameter: dia.4.2mm) 0.3 mm2 x 3 cores, 2 m
- Response Time: 0.5ms or less
- Light source (Light wavelength): Red LED (660nm)
- Connection: Cable type (outer diameter: dia.4.2mm) 0.3 mm2 x 3 cores, 2 m
- Volume (VR): 4 turn sensitivity adjustment without stopper provided
- Anti Interference feature: Available (up to two units)
- Material: Case:Polyarylate Lens:Polycarbonate (lens of GR12UVS: glass)
- Weight: approx. 80g
Output Mode:
- NPN open collector output
- Rating: sink current 100 mV (30 VDC) or less
Indicator:
- Red LED: Light reception indicator
- Green LED: Stability Indicator
Environmental Specifications:
- Ambient Light: 3,000 lx or more
- Ambient Temperature: -25°C - +55°C (non-freezing)/Storage -30°C- +70°C
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
- Shock: 1000 m/s2 / 3 times each in 3 directions
- Dielectric withstanding: 1,000 VAC for 1 minute
- Insulation resistance: 500 VDC, 20 MΩ or higher
- Shock: 1000 m/s2 / 3 times each in 3 directions
