FHDK 10P3101/KS35
Alt: 10146074, *Includes 6% Tariff from Manufacturer
$669.81
Photoelectric Through Beam Sensor, Receiver, 5m Sb/6m Sn Range, 270° Potentiometer, 10-30VDC, Dark Operate, PNP, <100mA, Rectangular 27 x 10.4 x 14mm (HWD), Plastic (ASA) Housing, PMMA Optics, Flylead Connector M8 3-Pin, -25 to +65°C, IP65
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Photoelectric Sensor
Specifications
Alternate Part Number
10146074, *Includes 6% Tariff from Manufacturer
Connection
w/Cable
Light Source
LED
NPN or PNP
PNP (Source)
Light On/Dark On
Dark ON
Sensing Method
Through Beam
Type of Photoelectric
General Purpose Photoelectric
All - Specific Ratings
IP65
Series
FHDK Series
Size
Rectangular
Warranty
3 Years
Weight
.5
Quantity
2
Features Include:
- Type: Through beam sensor
- Emitter / receiver: Receiver
- Actual range Sb: 5 m
- Nominal range Sn: 6 m
- Alignment / soiled lens indicator: Flashing light indicator
- Light indicator: LED yellow
- Sensitivity adjustment: Potentiometer, 270°
- Width / diameter: 10,4 mm
- Height / length: 27 mm
- Depth: 14 mm
- Type: Rectangular
- Housing material: Plastic (ASA)
- Front (optics): PMMA
- Connection types: Flylead connector M8 3 pin
