Diffuse Reflective Sensor, 24-240VAC/DC ±10? 50/60Hz Power Supply, 700mm (200-mm Square White Drawing Paper), Translucent Opaque Detection Object, Relay Output 1a, Light ON/Dark ON Selectable Switch (Integrated on Bottom of Sensor Unit), Re
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Photoelectric Power Supply, Through Beam, Red LED, 24/240VAC/DC, 10000mm Range, Relay, Terminal Block
Features Include:
- Detection Method: Diffuse reflective
- Detection Distance: 700mm (200-mm square white drawing paper)
- Detection Object: Translucent opaque
- Current Consumption: 25mA or less
- Power Supply: 24-240V AC/DC ±10% ± 50/60Hz
- Power Consumption: 2 W or less
- Output Mode: Relay output 1a / Rating: 2 A (250 VAC) or less resistance load
- Operation Mode: Light ON/Dark ON selectable. (with switch)
- Response Time: 5ms or less (*)
- Hysterisis: 10% or less
- Light source (light wavelength): Infrared LED
- Switch (SW): Light ON/Dark ON selector switch (integrated on bottom of sensor unit)
- Volume: Sensitivity adjustment (at receiver
- Material: Case : Acrylic
- Connection: Terminal block (with M3.5 screws)
- Weight: Transmitter/Reflector Approx. 250 g
Indicator:
- OP.L: operation indicator (red LED)
- STB: stability indicator (green LED)
Environmental Specifications:
- Ambient Light: 10,000 lx or less
- Ambient Temperature:-25 - +55°C (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 directions
- Shock: 500 m/s2 / 3 times each in 3 directions
- Dielectric withstanding: 1,500 VAC for 1 minute
- Insulation resistance: 500 VDC, 100 MΩ or higher
