GT7SN
Alt: Mini-G Series
$127.24
Photoelectric, NPN, Through Beam, 7m Range, 12-24VDC, Light ON/Dark ON, 2m Cable, IP67
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Ultra-compact size used for built-in use for over 25 years
- Various types such as head-on, wide diffuse reflective, high power or convergent reflective
- M3 threaded screw can be used for all models
- Water resistance complying with IP67
- Detection Method: Through Beam
- Detection Object: φ6mm (Min.) Opaque
- Current Consumption: Transmitter: 23mA max., Receiver: 18 mA max
- Power Supply: 24V DC ±10% / Ripple 10% max.
- Operation Mode: Light-ON / Dark-ON selectable (with switch)
- Hysteresis: 10% or less
- Response Time: 0.35ms or less
- Connection: Permanently attached cord (outer dimension: dia. 3) 0.15 sq. 4 core 2 m length(black)
- Light source (light wavelength): Red LED (700nm)
- Volume: SENS: Sensitivity adjustment (on receiver for through-beam type)
- Switch: Light-ON / Dark-ON selector switch
- Material: Case: Polyarylate, Lens: Polyarylate
- Weight: approx. 50g
Indicator:
- Red LED: Operation indicator
- Green LED: Stability Indicator
Environmental Specifications:
- Ambient Light: 5,000 lx or more
- Ambient Temperature:-25 - +55C (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction
- Shock: 500 m/s2 / 3 times each in 3 directions
- Dielectric withstanding: 1,000 VAC for 1 minute
- Insulation resistance: 500 VDC, 20 MΩ or higher
