Carlo Gavazzi
EO1804PPAS
Photoelectric Diffuse Reflective Sensor, M18, 10-40VDC, 400mm Range, PNP, 4-Wire Complementary, NO/NC, 2m PVC Cable, Modulated, Infrared Light 880nm, LED Indication, IP67
$135.11
Available Now!
Available Now!
(1 in stock)
EO1804PPAS-1
Alt: Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 5 Pieces., *Includes Tariff from Manufacturer
$144.79
Photoelectric Diffuse Reflective Sensor, M18, 10-40VDC, 400mm Range, PNP, 4-Wire Complementary, NO/NC, M12 Plug, Modulated, Infrared Light 880nm, LED Indication, IP67
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Carlo Gavazzi is a worldwide leader that designs and manufactures sensors, solid state relays and safety devices as well as monitoring relays, timers and energy management systems.
Carlo Gavazzi was founded in Milan, Italy in 1931 and the U.S. headquarters is located in Buffalo Grove, Illinois.
Specifications
Alternate Part Number
Minimum Order 1 is Limited to Available Stock Only! Then the Minimum will be 5 Pieces., *Includes Tariff from Manufacturer
Connection
Plug
Light Source
LED
NPN or PNP
PNP (Source)
Light On/Dark On
Light ON/Dark ON
Sensing Method
Diffuse Reflective
Type of Photoelectric
General Purpose Photoelectric
All - Specific Ratings
IP67
Size
See Spec
Quantity
1
Warranty
1 Year
Weight
.25
Series Features Include:
- Range: 400 mm adjustable
- Modulated, infrared light
- Supply voltage: 10 to 40 VDC
- Output: 200 mA NPN or PNP
- Make and break switching function, LED indication
- Protection: Reverse polarity, short-circuit, transients
- High immunity to ambient light
- Heavy duty M18 metal housing, IP67
- Cable and plug versions
