DLN-S5RV
Alt: DLN Series
$102.34
Photo Sensor, 50mm, NPN, Short, BGS/FGS Selector, 12-24VDC, Light ON/Dark ON, w/2m Cable, IP67
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Takex's DLN series is BGS (Background Suppression)/FGS (Background Recognition BGR) selectable!
Background Suppression sensors illuminate the detection object and the reflection is detected by the difference in light angles to and from the sensor.
Unlike diffusion reflective sensors, this group of sensors incorporates circuitry and optics to reduce or eliminate variations in received signal strength caused by: material on the lens, quality and variations in the material or color of the object being detected, etc.
- BGS/FGS dual function selectable
- BGS: Background suppression
- FGS: Background recognition (BGR)
- NPN/PNP dual output
- NPN/PNP primary output models available
- Mutual interference prevention function
Features Include:
- Sensing Distance: 10 to 50mm
- Ambient Light: 5,000 lx or less
- Ambient Temperature: -25 to +50°C
- Storage Temperature: -40 to +70°C (non-freezing/non-condensing)
- Ambient Humidity: 35 to 85%RH (non-condensing)
- Protective Structure: IP67
- Vibration: 10 to 55Hz double amplitude/1.5 2 hours each in 3 directions
- Shock: 500 m/s2 3 times each in 3 directions
- Dielectric Withstanding: 1,000 VAC 1 minute
- Insulation Resistance: 500 VDC megger, 20MΩ or more
