Dart Controls
SA-STOK-WO
5K Ohm Speed Pot Kit, 8.75" Leads, Knob, & Dial, Use When You Need an Input Device to Set Speed in VFD Applications, Ideal for Panel Mounting
$35.00
P1-03720-HFUF
Alt: SJ P1 Series
$15,129.32
VFD, 210hp, 3 Phase, 380-480V, 310/341/372 A, ND/LD/VLD, High Performance Vector Drive
- Weight:
- 210.00 LBS
- Minimum Purchase:
- 1 unit
Description
Hitachi first exported to the U.S. in 1926 and Hitachi America, Ltd. was established in 1959 with the first manufacturing facility opening here in 1977.
The Hitachi division we are an authorized distributor for is the Industrial Components and Equipment division which includes their low voltage AC drives/industrial inverters.
Series Features Include:
- Horsepower: 210 HP
- Heat sink designed for external mounting if required
- RS-485 Modbus RTU standard
- Energy saving function standard
- Keypad /Terminal switching
- Three-wire operation function
- Standard LCD color operator
- PID, Logic and time delay functions built in
- Arithmetic operation and delay functions
- Error codes in text
- Analog input disconnection detect function
- CE/UL/cUL/c-Tick approvals
- 10 year MTBF life design
- Loss of signal protection
- Sink or Source input compatible
- EzCOM for drive to drive master-less communications
- PID Sleep mode function and loss of pressure function
- PMAC motor compatible
Technical Information:
- Hitachi SJ Series P1 Variable Frequency Drive Brochure
- Hitachi SJ-P1 Series Variable Frequency Drive Quick Start Guide
- Hitachi SJ-P1 Series Variable Frequency Drive Basic Guide
- Hitachi SJ-P1 Series Variable Frequency Drive User Guide
- Hitachi VFD Cross Reference Guide
Technical Notices and Application Notes:
- Hitachi Pump Control with Variable Frequency Drives Application Note
- Hitachi "Sizing 3-Phase Inverters for Single-Phase Power Applications" Application Note
- Hitachi "Using ProDrive Software on PCs Only Equipped with USB Ports and No Serial Ports" Application Note
- Hitachi "Powering Inverters from a DC Supply" Application Note
- Hitachi "Minimizing Motor Shaft Bearing Current" Application Note
