Noark
EX9RD25A25
Overload Relay, Use with 9/12/18/25A Std, 17-25A, NR2-25G 17-25A, Use with EX9CDS/EX9CDR Contactors
$24.79
Product image is representative only, please verify specifications.
EX9RD25A2
Alt: 1410020
$24.79
Overload Relay, Use with 9/12/18/25A Std, 1.25-2A, NR2-25G 1.25-2A, Use with EX9CDS/EX9CDR Contactors
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Function: Thermal Overload
- Minimum Current: 1.25 A
- Maximum Current: 2 A
- Matched Fuse (aM): 4
- Matched Fuse (gG): 6
- Current: 25 A
- Compensation Temperature: -13 to 131 ºF, -25 to +55 ºC
- Use with Contactors: Ex9CM06~12
- Overload protection trip Class 10 A
- Phase loss sensitivity
- Adjustable current setting for overload protection
- Automatic or manual reset selectable
- Trip-free mechanism
- Status indication
- STOP and TEST function
- Direct mount to contactors or 35 mm DIN rail mounting base option
Technical Information:
Learn more about Contactors, Starters & Overload Relays here!
Accessories
Available Now!
Available Now!
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Noark
EX9RD25A2.5
Overload Relay, Use with 9/12/18/25A Std, 1.6-2.5A, NR2-25G 1.6-2.5A, Use with EX9CDS/EX9CDR Contactor
$24.79
