8801220100
$120.00
Oil-filled 1/2 NPT, Conn. 4-20mA: 0...10 Bar, DIN IP65, Rangeable Relative Pressure Transmitters, NP640 Series
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Configure Your Optimal AC Drive Solution
Build a complete solution with expert guidance on AC drives and compatible components including motors, circuit breakers and protection equipment
Description
Oil-filled 1/2 NPT, Conn. 4-20mA: 0...10 Bar DIN IP65, Rangeable Relative Pressure Transmitters
Specifications
Series
NP640 Series
Type of Product
USB Rangeable
Warranty
3 Years
Weight
0.5
Features Include:
- Process connection: external thread ¼ NPT, ½ NPT, ½ BSP or ¼ G
- Rangeability of the measurement: 3: 1
- Environmental conditions: -20 to 70 °C
- Accuracy, including hysteresis, linearity and repeatability: 0.25 % full scale (1.0 % for the 100 bar model)
- Materials in contact with the medium: 316L stainless steel
- Output: 4-20 mA 2-wire
- Electrical connection: DIN 43650 (EN 175301-803)
- Overpressure: 2 times the nominal pressure
- Dynamic response: <30 ms
- Power supply: 11-33 Vdc
Relative pressure ranges available:
- 0,1 MPa (1 bar)
- 0,4 MPa (4 bar)
- 1 MPa (10 bar)
- 2 MPa (20 bar)
- 4 MPa (40 bar)
- 10 MPa (100 bar)
Dimensions:
- ¼ NPT: Ø 27 x 88 mm
- ¼ G: Ø 27 x 89,4 mm
- ½ NPT: Ø 27 x 92,5 mm
- ½ BSP: Ø 27 x 86,5 mm
