295670-100065

Features Include:

• Effective detection range: 0 - 15 m
• Reflector distance: 0.02 - 15 m
• Threshold detection range: 18.5 m
• Reference target: H85-2 reflector
• Light source: LED
• Light type: modulated visible red light
• Diameter of the light spot: approx. 520 mm at a distance of 15 m
• Angle of divergence: 2°
• Operation indicator: LED green: constantly on - power on, flashing (4Hz) - short circuit, flashing with short break (1 Hz) - IO-Link mode
• Function indicator: Yellow LED: Permanently lit - light path clear, Permanently off - object detected, Flashing (4 Hz) - insufficient operating reserve
• Control elements: Light-on/dark-on changeover switch
• Control elements: sensitivity adjustment
• Operating voltage: 10 - 30 V DC
• Switching type: The switching type of the sensor is adjustable. The default setting is: C/Q - Pin4: NPN normally open / dark-on, PNP normally closed / light-on, IO-Link/Q - Pin2: NPN normally closed / light-on, PNP normally open / dark-on
• Signal output:  2 push-pull (4 in 1)outputs, short-circuit protected, reverse polarity protected, overvoltage protected
• Switching voltage: max. 30 V DC
• Switching current: max. 100 mA , resistive load
• Housing width: 15 mm
• Housing height: 61.7 mm
• Housing depth: 41.7 mm
• Degree of protection: IP67 / IP69 / IP69K
• Connection: 4-pin, M12 x 1 connector, 90° rotatable

Technical Information:

• Pepperl+Fuchs OBR15M-R201-2EP-IO-V1 Datasheet
• Pepperl+Fuchs IO-Link Offline Parameterization Installation and User Guide
• Pepperl+Fuchs R10x and R20x Series Sensor Product Catalog
