1C2DL
Alt: DL (C-Trip) Series
$27.29
MCCB, Miniature, UL489, 1-Pole, C-Curve, 2 Amp (2A), 125VDC, 10kA, DIN Rail Mounting, Molded Case Circuit Breaker, DL Series
- Weight:
- 0.35 LBS
- Minimum Purchase:
- 1 unit
Description
Altech Corporation was founded in 1984 and is a master distributor for a complete line of industrial automation components. Altech has been a long-time partner of ours and consistently brings high quality and unique products to the market.
They are located in Flemington, New Jersey and are ISO 9001:2015 certified.
Specifications
Amp Rating
2 Amp
Circuit Breaker Type
UL489
Poles
1 Pole
Series
DL Series (C-Trip)
Short Circuit Capacity
10kA
Trip Curve
C Curve
All - Voltage
125VDC
Warranty
1 Year
Alternate Part Number
DL (C-Trip) Series
Weight
0.35
Features Include:
- Rated Current: 2.0 A
- Rated Voltage: 125V DC
- Current/ Voltage Rating: 0.3 - 63A/ 125V DC
- Calibration Temperature: 40ºC (104ºF)
- Ambient Temperature: -25ºC to +55ºC (-13ºF to 131ºF )
- Storage Temperature: -40ºC to +70ºC (-40ºF to 158ºF )
- Terminal Torque (min/max): 2 Nm (17.7 lb.in.) / 2.5Nm (22.2 lb.in)
- Electrical Life: 6000 switching cycles ON/ OFF
- Mechanical Life: 10000 switching cycles ON/ OFF
- Vibration Resistance: > 15g according to DIN EN 60069-2-59 during a load with I1 = 1.05 x IN
- Resistance to mechanical shocks: 25g @ 11ms
