Product image is representative only, please verify specifications.
B1N1C25
Alt: 1000036
$14.11
Miniature Circuit Breaker, UL489, 1-Pole, C-Curve, 25A, 240VAC/60VDC, 10kA, Box Lugs
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
NOARK offers a full line of circuit protection and industrial controls. Products include circuit breakers, motor contactors, overload relays, safety contactors and relays.
CHINT's NOARK electrical products were originally released in Shanghai in 2009. Shortly after they re-branded CHINT to the NOARK brand in the United States.
Noark offers a 5-year limited warranty on all of their products!
Series Features Include:
- Complete range of UL 489 listed miniature circuit breakers up to a 63 A current rating
- Breakers mount on standard 35 mm DIN rail
- Standard ratings of 10 kA at 240 VAC and 10 kA at 60 VDC (1P) /125 VDC (2P)
- Suitable for branch circuit device protection
- Trip-free design - breaker cannot be defeated by holding the handle in the ON position
- Captive screws cannot be lost
- For use in applications for which UL 1077 or CSA C22.2 No.235 are also allowed
- Field installable shunt trip and auxiliary switch subsequent mounting
- Available with provisions for ring tongue terminals
- Module width of only 0.71 in (18 mm) per pole
- Contact position indicator (red/green)
- Possibility for locking the toggle in ON or OFF position
Technical Information:
