Meter Relay, Rugged, Percent Motor Load, 4.5", 0-150%, Model 3344 AIXA
- Weight:
- 1.20 LBS
- Minimum Purchase:
- 1 unit
Description
Meter Relay, Rugged, Percent Motor Load, 4.5", 0-150%, Model 3344 AIXA
Features Include:
- Power: 108-132 VAC, 50-400Hz
- Accuracy: ±3% of full scale (F.S.)
- Movement: Annular, self-shielding
- Switching: Within 1% of indication
- Frequency Response: 50-1000Hz
- Operating Temperature: 41ºF to +122ºF (+5ºC to +50ºC )
- Repeatability: Within 0.5% F.S.
- Overload (1 sec.): 10 times F.S.
- Resistance: ±15%
- Provides Visual Monitoring of Load Conditions of AC Current Motors
- Built-in Adjustable Time Delay (Delays up to 20
- Seconds Available on Special Order)
- Calibration Not Affected by Steel Panel Mounting
- Rugged Metal Case for Rigorous Environments
- Commercially-Sealed, Moisture and Dust Proof
- Amplifier Input
