DWB100JE80-3DX
Alt: 12736121
$185.28
MCCB, 80A@480Y/277VAC, 14kA IC, 80% Rated, 3-Pole, UL489, Fixed Thermal/Magnetic
- Weight:
- 3.00 LBS
- Minimum Purchase:
- 1 unit
Description
Our WEG DWB series of UL489 Listed molded case circuit breakers (MCCB) offers four compact frames and protection from 20 to 600 amps. This series is also available in two versions; standard 80% rated and premium 100% rated.
Choose from 3 short circuit ratings; 10kA, 14kA or 35kA.
Marshall Wolf Automation is your authorized stocking distributor for WEG products!
Specifications
Alternate Part Number
12736121
Amp Rating
80 Amp
Circuit Breaker Type
Molded Case (MCCB)
Poles
3 Pole
Series
DWB Series
Short Circuit Capacity
14kA
Trip Curve
MCCB - Molded Case
All - Voltage
480Y/277VAC
Warranty
18 Months
Weight
3
Features Include:
- Compact Size
- Accessory for DIN mounting
- Fixed Thermal- Fixed Magnetic trip unit
- Transparent cover for easy accessory recognition
- Complete line of field installable accessories
- Suitable for reverse feed applications
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
$51.20
Weg
BCAL-2 DWB
Auxillary & Alarm Contact Set BCAL-1BC+1AL ContactUse with DWB MCCB, DWB100/250/400/600
$51.20
