Carlo Gavazzi is a worldwide leader that designs and manufactures sensors, solid state relays and safety devices as well as monitoring relays, timers and energy management systems.
Carlo Gavazzi was founded in Milan, Italy in 1931 and the U.S. headquarters is located in Buffalo Grove, Illinois.
Series Features Include:
Protection of circuits against short circuit and overload currents
UL1077 supplementary protection
1, 2, 3 and 4 pole arrangements
13 amperage sizes up to 63Amps
Insulation Voltage: 500 VAC
Rated Voltage: Single Phase: 277 VAC / Three-Phase: 480Y/277VAC
Rated Frequency: 50/60 Hz
Rated Breaking Capacity: 5,000 A
Mounting: Vertical on DIN rail EN 60715 (35mm)
Connection: Line-in on top, line-out on bottom
Icn of 5kA
Bimetallic element for small overloads
Magnetic element for short circuit protection
B, C, D trip characteristics
Full line of bus bars and connectors
Auxiliary contact, alarm switch and shunt release accessories
