UMBW-4C3-8
Weg

UMBW-4C3-8

Alt: 14362807, Replacement for UMBW-4B3-7 (14361494), UMBW-4B3-8 (14361495) and UMBW-4C3-7 (14362806)

$58.46

MCB, UL489, 3-Pole, C-Curve, 8 Amp, 277/480Y VAC, 125VDC, 10kA, Thermal-Magnetic Miniature Circuit Breaker, IP20, UMBW Series

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Configure Your Optimal Enclosure Solution
Choose the right enclosure with expert recommendations on compatible accessories like subpanels, fans, filters, heaters, thermostats, air conditioning units, and heat exchangers.
Description

WEG's UMBW series of UL miniature circuit breakers are available in UL1077 and UL489 with B, C or D trip curves.

  • Available from 1 to 63 amp
  • 1, 2 or 3 pole
  • B, C or D trip curves
  • Single or multi-pole
  • UL1077 (supplementary protector) or UL489 (branch circuit protective device)
    • UMBW-1 are UL1077
    • UMBW-4 are UL489
  • AC and DC voltages available in one series
  • 17.5mm width per pole
  • Positive trip-free snap action mechanism for reliable switching
  • Cuttable bus bar connecting system
  • Other WEG series include:
    • MPW series of manual motor protectors (MMP)
    • UBW/DWB series of molded case circuit breakers (MCCB)

Marshall Wolf Automation is a stocking distributor for the complete line of WEG products!

Specifications
Alternate Part Number 14362807, Replacement for UMBW-4B3-7 (14361494), UMBW-4B3-8 (14361495) and UMBW-4C3-7 (14362806)
Amp Rating 8 Amp
Circuit Breaker Type UL489
Poles 3 Pole
Series UMBW Series
Short Circuit Capacity 10kA
Trip Curve C Curve
All - Voltage 277/480Y VAC
Warranty 18 Months
Weight 1

UMBW Series Features Include:

  • AC & DC voltages available in one series
  • UL489 Branch Circuit protective device
  • UL1077 Equipment protection
  • 17.5mm width per pole
  • Visual status indication
  • Positive trip-free snap action mechanism to ensure reliable switching
  • Cuttable Bus Bar connecting system
  • Ambient Temperature Rating: -35°C to +70°C
