UMBW-4C1-15
Weg

UMBW-4C1-15

Alt: 14361805, Replacement for UMBW-4B1-15 (14360169), UMBW-4B1-16 (14360170) and UMBW-4C1-16 (13634520)

$19.61

MCB, UL489, 1-Pole, C-Curve, 15 Amp, 277VAC/60VDC, 10kA, Thermal-Magnetic Miniature Circuit Breaker, IP20, UMBW Series This is the Recommended Replacement for UMBW-4B1-15 (14360169), UMBW-4B1-16 (14360170) and UMBW-4C1-16 (13634520)

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description

WEG's UMBW series of UL miniature circuit breakers are available in UL1077 and UL489 with B, C or D trip curves.

  • Available from 1 to 63 amp
  • 1, 2 or 3 pole
  • B, C or D trip curves
  • Single or multi-pole
  • UL1077 (supplementary protector) or UL489 (branch circuit protective device)
    • UMBW-1 are UL1077
    • UMBW-4 are UL489
  • AC and DC voltages available in one series
  • 17.5mm width per pole
  • Positive trip-free snap action mechanism for reliable switching
  • Cuttable bus bar connecting system
  • Other WEG series include:
    • MPW series of manual motor protectors (MMP)
    • UBW/DWB series of molded case circuit breakers (MCCB)

Marshall Wolf Automation is a stocking distributor for the complete line of WEG products!

UMBW Series Features Include:

  • AC & DC voltages available in one series
  • UL489 Branch Circuit protective device
  • UL1077 Equipment protection
  • 17.5mm width per pole
  • Visual status indication
  • Positive trip-free snap action mechanism to ensure reliable switching
  • Cuttable Bus Bar connecting system
  • Ambient Temperature Rating: -35°C to +70°C
