612.1140.832
Alt: GC-U1 FF
$184.49
Limit Switch, Wobble Stick w/Slide, 1NC/1NO, 240VAC, 10A, Die Cast Aluminum Body, IP65
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Bernstein is a German manufacturer of industrial safety and enclosure technology and are well known for a wide range of sensors, switches, enclosures and operating terminals.
If you do not see the part number you are looking for, please Contact Us, we can find what you need!
Features Include:
- Rated Insulation Voltage: 400 V
- Conventional Thermal Current: 10 A
- Rated Operating Voltage: 240 V AC
- Short-Circuit Protection (up to): Fuse 10 A gG
- Enclosure Material: Aluminum pressure die-casting
- Cover: Sheet aluminum
- Actuator: Wobble stick with plastic slide
- Connection: 4 screw connections (M3.5)
- Contact Type: 1 N.C., 1 N.O. (Za)
- Cable Entrance: Cable gland (M20x1.5) (clamp-range 5,5 – 6,1 mm)
- Type: Zb (galvanically isolated changeover contact)
- Protection class IP 65 to VDE 0470 T1
- Actuator can be repositioned by 4 x 90°
- Connection designation conforming to DIN EN 50013
- Metal actuators for high loads
