602.1190.100

Features Include:

• Rated Insulation Voltage: 400 V AC
• Conventional Thermal Current: 10 A
• Rated Operating Voltage: 240 V
• Short-Circuit Protection (up to): Fuse 2 A gG
• Enclosure Material: Aluminum pressure die-casting
• Cover: Sheet aluminum
• Actuator: Wobble stick with plastic slide
• Connection: 4 screw connections (M3.5)
• Contact Type: 1 N.C., 1 N.O. (Zb)
• Cable Entrance: Cable gland (M20x1.5) (clamp-range 5,5 – 6,1 mm)
• Type: Zb (galvanically isolated changeover contact)
• Protection class IP 65 to VDE 0470 T1
• Actuator can be repositioned by 4 x 90°
• Connection designation conforming to DIN EN 50013
• Metal actuators for high loads
