608.8117.007
Alt: TI2-U1Z RIW
$57.25
Limit Switch, Roller, Slow Action, 1NC/1NO, 240V, 10A, Plastic Body, IP65
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Insulation Voltage: 250 V AC
- Conv. Thermal Current: 10 A
- Rated Operational Voltage: 240 V
- Short-Circuit Protective Device: Fuse 6 A gG
- Actuator: Roller (thermoplastic)
- Enclosure: Thermoplastic, glass fiber reinforced (UL 94-V0)
- Connection: 4 screw connections (M3,5)
- Protection Class: II, totally insulated
- Optimized size while retaining tried-and-tested connection system
- Two-channel safety monitoring possible
- With captive snap-on cover
- 2 mm contact opening width of slow-action system conforming to EN 81-1 for lift construction
- Mall hysteresis in snap action system
- Actuator can be repositioned by 4 x 90°
