Light Tower, Wall Mount, Red/Green/Amber, 24VDC, 80mm, LED Continuous/Flashing Light, Alarm, Off-White
- Weight:
- 1.10 LBS
- Minimum Purchase:
- 1 unit
Build Your Complete VFD Solution
Create a complete system with recommendations on AC drives and compatible components like motors, circuit breakers, and protection equipment.
Description
The WME-D series is a flush mounted, wall mount, 80mm profile, LED signal tower.
This light tower is easy to install (mounting bracket included!) and can withstand accidental impacts. Compared to the WME-A series these have ultra-bright LEDs, a louder alarm and a more durable outer shell.
Patlite has discontinued the WME-A series and replaced it with the WME-D series.
The WME-D series has brighter LED lgihts and is an off-white color, the WME-A was an ivory color.
Please note on the 24 volt models: the WME-A series was 24VAC/DC, the new WME-D series is 24VDC only.
Specifications
All - Approvals
CE, UL Recognized
Light Tower Body Color
White/Ivory
Diameter
80mm
Light Tower Mounting
Wall Mount
Light Tower Number of Stacks
3 Light Stack
Light Tower Options
Buzzer/Audible Alarm, Continuous and/or Flashing, LED
All - Specific Ratings
IP54
Series
WME Series
All - Voltage
24VDC
Alternate Part Number
WME Series
Warranty
1 Year
Weight
1.1
Features Include:
- FB type: Built-in audible alarm up to 93dB (at 1m).
- Installation: Easy vertical and horizontal installation with mounting bracket.
- Interchangeable Modules: No re-wiring even after installation.
- Mount option: Compatible with household switch box (JISC 8336 with 82.5m pitch).
- Main body: Made of PC resin.
- Lens: Superior impact and heat resistant polycarbonate resin for superior durability and light transmission.
- NPN/PNP Compatible: 24V DC type ONLY.
- LED Module Colors: Red, Amber, Green, Blue, White.
