ESN-T20
Alt: ESN Series
$569.78
Light Curtain, Thru-Beam, NPN, Red LED, 5m Range, Ø30
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Light Curtain Sensor, Through Beam, NPN, Red LED, 5000mm, 30dia,
Features Include:
- Master/Slave operation for installation of up to 2 adjacent units
- Auto Sensitivity Compensation (from set point) to offset lens soiling
- Capable of detecting objects 30mm or larger (opaque)
- Terminal board connection ensures open space at writing
- Detection Distance: 5m or less
- Detection Method: Through Beam
- Detection Object: Opaque dia.30mm or more
- Beam Interval: 20mm
- Number of Light Axes: 20
- Detecting Width: 380mm
- Power Supply: 12 - 24V DC ±10% / Ripple 10% or less
- Current Consumption: 130mA or less
- Output Mode: Open collector output Rating: Sink current 100mA (30VDC) or less
- Operation Mode: Activated when light beams of all axes are received (deactivated when light beam of any axis is blocked)
- Response Time: 7ms or less
- Light Source: Infrared LED (850nm)
- Light Receiving Element: Photo IC
- Material: Case: ABS / Indicator window: acrylic
- Connection: Attached Cable (Outer dimension: dia.4.3mm) Cable: 3 m, Cable: With five 0.2 mm 2 5 cores, gray (transmitter) or black (receiver) covering
- Auxiliary Functions: Automatic sensitivity compensation, Anti Mutual Sensitivity feature for adjacent installation, Output short circuit protection
Indicator:
- Transmitter - Green LED: Power Indicator | Red LED: Operation Indicator
- Receiver: Green LED: Stable light reception indicator | Red LED: Operation Indicator
Environmental Factors:
- Ambient Light: 10,000 lx or less
- Ambient Temperature: -10 - +55°C (non-freezing)
- Ambient Humidity: 35 - 85%RH (non-condensing)
- Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 directions
- Shock: 500 m/s2 / 3 times each in 3 directions
- Dielectric Withstanding: 1000VAC for 1 minute / between entire live part and case
- Insulation Resistance: 500 VDC, 20 MΩor higher
