101216746
Alt: SLC440-ER-1130-30-01
$3,083.00
Light Curtain, Protection Field Height 1130mm, Resolution 30mm, Range 0,3 m ... 10 m
- Weight:
- 4.00 LBS
- Minimum Purchase:
- 1 unit
Description
Light Curtain, Protection field height 1130 mm Resolution 30 mm, Range 0,3 m ... 10 m
Features Include:
- Detection Ability for Test Bodies: 30
- Beams: 56
- Design of output switching element OSSD: PNP
- Switching voltage of the OSSD in high state: 24 VDC ± 20%
- Protection Field Height: 1130 mm
- Range of Protection Field: 300 -10,000
- Wavelength of Sensors: 880
- Housing Material: Aluminum
Dimensions:
- Width of Sensor: 27.8
- Height of Transmitter: 1221 mm
- Height of Receiver: 1211 mm
- Diameter of Sensor: 33 mm
Connections:
- Wiring of the transmitter: Connector plug M12, 4-pole
- Wiring of the Receiver: Connector plug M12, 8-pole
