Alt: SLC440-ER-1130-14-01

$4,173.00

Light Curtain, Protection Field Height 1130mm, Resolution 14mm, Range 0,3 m ... 7 m

Weight:
3.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Light Curtain, Protection field height 1130 mm Resolution 14 mm, Range 0,3 m ... 7 m

Features Include:

  • Detection Ability for Test Bodies: 14
  • Beams: 112
  • Design of output switching element OSSD: PNP
  • Switching voltage of the OSSD in high state: 24 VDC ± 20%
  • Protection Field Height: 1130
  • Range of Protection Field: 300 -7000
  • Wavelength of Sensors: 880
  • Housing Material: Aluminum

Dimensions:

  • Width of Sensor: 27.8
  • Height of Transmitter: 1221 mm
  • Height of Receiver: 1211 mm
  • Diameter of Sensor: 33 mm

Connections:

  • Wiring of the transmitter: Connector plug M12, 4-pole
  • Wiring of the Receiver: Connector plug M12, 8-pole
