Kacon
KSR5040ZAHF
SSR with Heatsink and Fan, Single Phase, Input 90-240VAC, 40 Amp (40A), Load Voltage 90-480VAC, Zero Crossing, Over Temperature Alarm, Solid State Relay, KSR Series
$94.51
Product image is representative only, please verify specifications.
KSR5040ZAH
Alt: KSR Series
$81.98
SSR with Heatsink, Single Phase, Input 90-240VAC, 40 Amp (40A), Load Voltage 90-480VAC, Zero Crossing, Over Temperature Alarm, KSR Series
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Rated Load Voltage AC: 440V (50/60Hz)
- Input Voltage: 220VAC(90-240V 50/60Hz)
- Input Voltage Range AC: 90-480V (50/60Hz)
- Load Current Range: 0.5A - Rated Current @ Ambient Temp of 25°C
- Peak Voltage: 1,200V
- Heatsink Type: Heatsink
- Slim type single phase SSR
- LED indicator of the control input status
- Over heat alarm output of SSR with connector cable
- Heatsink integrated SSR available
- NPN Open Collector
Technical Information:
