Kacon
KMSR-DS0252
SSR, Hockey Puck, Single Phase, Input 4-32VDC, 25 Amp (25A), Load Voltage 90-240VAC, Zero Crossing, Solid State Relay, KMSR Series
$26.40
**Happy New Year! Our offices will close at Noon on December 31st, reopening on January 2nd.**
KMSR-DS0204
Alt: KMSR Series
$26.94
SSR, Hockey Puck, Single Phase, Input 4-32VDC, 20 Amp (20A), Load Voltage 90-480VAC, Zero Crossing, Solid State Relay, KMSR Series
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
The KMSR series is a cost-effective hockey puck style solid state relay that is available in single or three phase.
Features Include:
- Rated Input Control Voltage: 4 -32VDC
- Input Current: 3 - 35mA
- Pick-up Voltage: 3VDC Minimum
- Drop-out Voltage: 1.5VDC Maximum
- Rated Output Load Voltage: 90 - 480VAC
- Peak Output Voltage: 1200V
- Frequency: 47-63 Hz
- Output Leakage Current (Maximum): 20mA
- Minimum Switching Current: 1A
- Pick-up/Drop-out Time: 1/2 cycle+1ms Maximum
- Insulation Resistance: 100MΩ/500VDC (btwn Terminal & Case)
- LED indicator of the control input status
- Clip cover of IP20 touch protection
Technical Information:
