KMSR-AS0254

KMSR-AS0254

Alt: KMSR Series

$26.94

SSR, Hockey Puck, Single Phase, Input 90-264VAC, 25 Amp (25A), Load Voltage 90-480VAC, Zero Crossing, Solid State Relay, KMSR Series

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description

The KMSR series is a cost-effective hockey puck style solid state relay that is available in single or three phase.

Features Include:

  • Rated Input Control Voltage: 90 - 265 VAC
  • Input Current: 15mA Maximum
  • Rated Output Load Voltage: 90 - 480VAC
  • Peak Output Voltage: 1200V
  • Insulation Resistance: 100MΩ/500VDC (btwn Terminal & Case)
  • Dielectric Strength: 2500VAC(50/60Hz 1minute)
  • Vibration Resistance: 10-55Hz, amplitude: 1.5mm,x,y,z each axis 2 hours
  • Shock Resistance: 100m/s²,s,y,z each axis 3times
  • LED indicator of the control input status
  • Clip cover of IP20 touch protection

Technical Information:
