Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.



Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Series Features Include:

• Front panel installation according to IEC 947-5-1 D30
• Pushbutton with actuating directions 1-4
• One changeover contact with tab connector 2.8 x 0.5 IEC 760 for each actuating direction
• Bellows
• Pushbutton in handle
• All-round actuation
• Actuating side with/without bellow: IP 65
• Rated impulse withstand voltage Uimp: 2.5 kV
  Rated insulation voltage Ui: 250 V
• Weight Approx.: 0.17 kg
• Mounting type: IEC 947-5-1 D30
• Number of monitoring contacts: 4
• Actuating force 3 N
• Switching principle: Changeover contact C, IEC 947-5-1
• Material: Contact Silver alloy, Switching lever stainless steel, Bellows elastomer, black, Housing thermoplastic/aluminum

Technical Information:

• Euchner Joystick Switches Catalog
