110480

Euchner is a leading global manufacturer of a complete line of safety solutions. Their products include a full line of safety switches; limit, interlock, foot, rope pull and emergency stop. They also offer safety controllers, light curtains, multifunctional gate boxes and ID systems.



Founded by Emil Euchner in 1940, Euchner remains a family owned company.

Series Features Include:

• Front panel installation according to IEC 947-5-1 D30
• 1 to 8 actuating directions with spring return switches or combined
• One changeover contact with tab connector 2.8 x 0.5 IEC 760 for each actuating direction
• Center position switch
• Pushbutton in handle
• Housing material: Reinforced thermoplastic/aluminum
• Switching lever: material Stainless steel
• Actuating side with/without bellow: IP 65/IP 54
• Weight Approx.: 0.2 kg
• Connection: Tab connector 2.8 x 0.5 IEC 760
• Switching contact: 1 x NO contact (NC contact/changeover contact on request)
• Switching principle: Snap-action contact element, design ES 584
• Utilization category AC 15: 230 V/2 A
• Utilization category DC 13: 24 V/1 A

Technical Information:

• Euchner Joystick Switches Catalog
