078640

Series Features Include:

• Front panel installation according to IEC 947-5-1 D30
• One changeover contact with tab connector 2.8 x 0.5 IEC 760 for each actuating direction
• Switching lever engages in selected position)
• Actuating side with/without bellow: IP 65
• Weight Approx.: 0.17 kg
• Utilization category AC 15: 230V 4A
• Utilization category DC 13: 24V 2A
• Rated insulation voltage Ui: 250 V
• Rated impulse withstand voltage Uimp: 2.5 kV
• Switching contact: 1 x NO contact
• Material: Housing: thermoplastic/aluminum, Switching lever: stainless steel, Bellows: elastomer black

Technical Information:

• Euchner Joystick Switches Catalog
