$252.00
ADAM-4520-F
Alt: This Item Replaced ADAM-4520-EE
$112.40
Isolated RS-232 (DB9) to RS-422 (4-Wire)/485 (2-Wire) Converter, 10-30VDC, Revision EE
- Minimum Purchase:
- 1 unit
Description
Features of the ADAM-4520-EE:
- Automatic RS-485 data flow control
- 3000 VDC isolation protection
- Surge protection RS-485 data line
- Transmission speed up to 115.2 Kbps
- Networking up to 1200 meters (4000 feet)
- Reserved space for termination resistors
- Power and data flow indicator for troubleshooting
- Power requirement: +10 to +30 VDC
- Mounts easily on a DIN-rail, panel or piggyback
Features Include:
- Connectors: 1 x plug-in terminal block (#14 ~ 22 AWG) (RS-422/485) 1 x DB9-F (RS-232)
- Isolation Voltage: 3,000 VDC
- Power Consumption: 1.2 W @ 24 VDC
- Power Input: Unregulated 10 ~ 30 VDC w/ power reversal protection
- Input: RS-232 (DB9)
- Output: RS-485 (2-wire) or RS-422 (4-wire)
Technical Information:
- Advantech ADAM-4510/S, -4520, -4521 Series Specifications
- Advantech ADAM-4000 Series User Manual
- Advantech ADAM-4000 Series Access Port Instructions
- Advantech ADAM-4000 Series AIO Calibration Instructions
- Advantech ADAM-4000 Series Reconnection Instructions
- Advantech ADAM-4000 Series DO Voltage/Current Datasheet
- Advantech ADAM-4000 Series Tolerance Range Datasheet
