306533-0007
Alt: NRN15-18GM40-E2-IO-C-V1
$201.25
Inductive Sensor, Non-Flush, 15mm Range, Weld-Immune, 18mm Housing, PNP, IO-Link, RF1, M12
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Specifications
Alternate Part Number
NRN15-18GM40-E2-IO-C-V1
Connection
M12, Straight
Material
PTFE Coated Brass
Normally Open/Closed
Normally Open/Closed (NO/NC)
NPN or PNP
PNP (Source)
All - Specific Ratings
IP67
Series
NR Series
Shielded/Unshielded
Unshielded - Non-Flush
Size
18mm
Type of Sensor
Inductive
All - Voltage
10-30VDC
Warranty
18 Months
Weight
0.25
Features Include:
- 15 mm non-flush
- Reduction factor = 1
- Magnetic field resistant
- Weld Immune
- IO-link interface for service and process data
- Switch point mode or window mode can be set
- Switching function, stability alarm and pulse extension can be set
- Switching function: Normally open/closed (NO/NC) programmable
- Output type: PNP
- Rated operating distance: 15 mm (factory setting)
- Operating voltage: 10 - 30 V DC
- Connection type: Connector plug M12 x 1 , 4-pin
- Housing material: Brass, PTFE coated
