326161-0053

326161-0053

Alt: NBN8-12GM50-E0-V1, (Was 088241)

$93.58

Inductive Proximity Sensor, Ø12mm, 3-Wire, 8mm Range, NPN NO, M12

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Inductive Proximity Sensor, 12mm Dia., 3-Wire, NPN, NO, M12

Ever wondered how to really pronounce "Pepperl+Fuchs"? Learn how here!

Specifications
Alternate Part Number NBN8-12GM50-E0-V1, (Was 088241)
Connection M12, Straight
Material Nickel Plated Brass
Normally Open/Closed Normally Open (NO)
NPN or PNP NPN (Sink)
All - Specific Ratings IP67
Series NBN Series
Shielded/Unshielded Unshielded - Non-Flush
Size 8mm
Type of Sensor Inductive
All - Voltage 10-30VDC
Warranty 18 Months
Weight 0.25

Features Include:

  • Rated Operating Distance: 8 mm
  • Installation: Non-Flush
  • Assured Operating Distance: 0 - 6.48 mm
  • Switching Frequency: 0 - 1500 Hz
  • Operating Voltage: 10 - 30 V
  • Operating Current: 0 - 200 mA
  • Connection Type: Connector M12 x 1, 4-pin
  • Housing Diameter: 12 mm
  • Short-Circuit Protection: Pulsing
  • Switching State Indicator: Multihole-LED, yellow
  • Ambient Temperature: -25 - 70 °C (-13 - 158 °F)
  • Sensing Face: PBT
