IFRM 06N17A3/S35L
Baumer

IFRM 06N17A3/S35L

Alt: 10140591, *Includes Tariff

$116.70

Inductive Proximity Sensor, Ø6.5x36mm, Flush, 10-30VDC, 2mm Range, NPN NO, M8 Connector, IP67, Generally Available to Ship in 3 to 5 Days, Effective April 14th, 2025: This Item Includes a 6% Tariff That The Manufacturer Has Added

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Inductive Proximity Sensor, Ø6.5x36mm, Flush, 10-30VDC, 2mm Range, NPN NO, M8 Connector, IP67
Specifications
Alternate Part Number 10140591, *Includes Tariff
Connection M8, Straight
Material Stainless Steel
Normally Open/Closed Normally Open (NO)
NPN or PNP NPN (Sink)
All - Specific Ratings IP67
Series IFRM Series
Shielded/Unshielded Shielded - Flush
Size 6mm
Type of Sensor Inductive
All - Voltage 10-30VDC
Warranty 3 Years
Weight .5

Features Include:

  • Nominal Sensing Distance Sn: 2 mm
  • Mounting Type: Flush
  • Hysteresis: 3 - 20% of Sr
  • Output Indicator: 3 port LED red
  • Switching Frequency:< 5 kHz
  • Voltage Supply Range +Vs:10 - 30 VDC
  • Current Consumption Max. (no load): 12 mA
  • Voltage Drop: < 2 VDC
  • Output Current: < 200 mA
  • Material (sensing face): PBT
  • Housing Material: Stainless Steel
