023490
Alt: NEB22-30GM60-E2-V1
$179.11
Inductive Proximity Sensor, Ø30mm, Quasi-Flush, 10-30VDC, 22mm Range, PNP, NO, M12 4-Pin Connector, IP67
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Pepperl+Fuchs was founded in 1945 as a small radio workshop in Germany by Walter Pepperl and Ludwig Fuchs. They eventually invented the proximity switch!
Their products include proximity, ultrasonic and photoelectric sensors, explosion protection products, visions systems as well as connectivity and remote I/O options.
The U.S headquarters is located in Twinsburg, Ohio.
Features Include:
- Switching Element Function: PNP Normally Open (NO)
- Output Polarity: DC
- Rated Operating Distance: 22 mm
- Assured Operating Distance: 0 - 17.8 mm
- Operating Voltage: 10 - 30 V
- Switching Frequency: 0 - 150 Hz
- Operating Current: 0 - 200 mA
- Switching State Indicator: LED, yellow
- Installation: Quasi-Flush
- Connection Type: Connector M12 x 1, 4-pin
- Housing Material/Sensing Face: PBT
