Baumer
IFRM 18N13T1/S14L
Inductive Proximity Sensor, Ø18x60mm, NonFlush OD, 10-30VDC, 12mm Range, NPN NO, M12 Connector, IP67
$149.00
IFRM 18N13T1/PL
Alt: 11016659
$164.00
Inductive Proximity Sensor, Ø18x50mm, NonFlush OD, 10-30VDC, 12mm Range, NPN NO, 2m PUR Cable, IP67
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Inductive Proximity Sensor, Ø18x50mm, NonFlush OD, 10-30VDC, 12mm Range, NPN NO, 2m PUR Cable, IP67
Features Include:
- Nominal Sensing Distance Sn: 8 mm
- Mounting Type: Non-Flush
- Hysteresis: 3 - 20% of Sr
- Output Indicator: 4 port LED red
- Switching Frequency:< 500 kHz
- Voltage Supply Range +Vs:10 - 50 VDC
- Current Consumption Max. (no load): 10 mA
- Voltage Drop: < 2 VDC
- Output Current: < 200 mA
- Material (sensing face): PBT
- Housing Material: Nickel Plated Brass
