Autonics
PRDL18-14DP2
Inductive Proximity Sensor, 18mm Round Long, 3-Wite, Non-Shielded, 10-30VDC, 14mm Sensing, PNP, NC
$39.00
PRDL18-14DP
$39.00
Inductive Proximity Sensor, Ø18mm, 14mm Range, 3-Wire DC Non-Shielded, PNP NO, M18, 12-24VDC IP67
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Inductive Proximity Sensor, Ø18mm, 14mm Range, 3-Wire DC Non-Shielded, PNP NO, M18, 12-24VDC IP67
Features Include:
- Wire type and power: DC 3-wire type 12-24VDC
- Sensing side diameter: M18
- Sensing distance: 14mm
- Installation: Non-shield (non-flush)
- Standard sensing target: 40×40×1mm(iron)
- Response frequency: 200Hz
- Current specification: Current consumption: Max. 10mA
- Control output: PNP Normally Open
- Material: Brass(nickel plated)
- Cable Standard/material: Standard cable
- Protection structure: IP67
- Body length: Long body
- Environment - Ambient temperature: -25 to 70°, storage: -30 to 80°
- Environment - Ambient humidity: 35 to 95% RH, storage: 35 to 95% RH
- Hysteresis (distance): Max. 10% of sensing distance
- Residual voltage: Max. 1.5V
- Weight Approx.: 140g
