ICB12S30N08POM1
Alt: Minimum Order 10 Pieces, Price per Piece
$57.60
Inductive Proximity Sensor, Ø12mm, Non-Flush, 10-36VDC, 8mm Range, 200mA PNP NO, Short, M12 Plug
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 10 units
Description
Inductive Proximity Sensor, Ø12mm, NonFlush, 10-36VDC, 8mm Range, 200mA PNP NO, Short, M12 Plug
Specifications
Alternate Part Number
Minimum Order 10 Pieces, Price per Piece
Connection
Quick Disconnect
Material
Nickel Plated Brass
Normally Open/Closed
Normally Open (NO)
NPN or PNP
PNP (Source)
All - Specific Ratings
IP67
Series
ICB Series
Shielded/Unshielded
Unshielded - Non-Flush
Size
8mm
Type of Sensor
Inductive
All - Voltage
36VDC
Warranty
1 Year
Weight
0.25
Features Include:
- Sensing distance: 8 mm
- Non-Flush type
- Rated operational voltage (Ub): 10 - 36 VDC
- Output: DC 200 mA, PNP
- Normally open
- LED indication for output ON
- Protection: reverse polarity, short circuit, transients
- According to IEC 60947-5-2
- Higher resistance to magnetic field
- CSA certified for Hazardous Locations
