Available Now! HR710-2PL-24VDC
Available Now! (1 in stock)
Kacon

HR710-2PL-24VDC

$7.04

Ice Cube Relay, 10A DPDT, 24VDC Input, LED, Socket Required

Weight:
0.25 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
KACON is a Korean manufacturer for a full line of switches and control components. They work with many international brands and are sold through key distributors around the world.

Their products are readily available from Illinois and they have very competitive pricing.

Features Include:

  • Configuration: DPDT (2NO + 2NC)
  • Material: Ag alloy (24K gold plate)
  • Max. Switching Current: 10A
  • Rated Max. Resistive Load: 10A at 24VDC/220VAC
  • Max. Switching Voltage: 125VDC/ 250VAC 50/60Hz
  • Min. Switching Requirement: 100mA 5VDC
  • Operating Time: 25ms
  • Insulation Resistance: 100MΩ at 500V DC
  • Vibration Resistant: 10~55Hz at double amplitude of 1.5mm
  • 705 Series are designed with compact housing & ICE cube style, silver alloy contact, LED indicator, high reliability and long life
  • Available Serge protection type to protect malfunction of PLC, electronic devices from back EMF
