MT8070IE
Alt: iE Series
$666.75
HMI, 7.0", Plastic, 600MHz, with Ethernet, Class 1 Div 2
- Weight:
- 2.00 LBS
- Minimum Purchase:
- 1 unit
Description
Weintek is a global HMI manufacturer that continues to develop and design cutting edge HMI options.
Founded in 1996, Weintek 7" and 10" 16:9 touchscreens have become a standard in the industry.
Features Include:
- Input Power: 24±20%VDC
- Power Isolation: N/A
- Power Consumption: 350mA @ 24VDC
- Dimensions (WxHxD): 200.3 x 143.3 x 32 mm
- Panel Cutout: 119 x 93 mm
- Voltage Resistance: 500VAC (1 min)
- Isolation Resistance: Exceed 50MΩ at 500VDC
- Vibration Endurance: 10 to 25Hz (X, Y, Z direction 2G 30 minutes)
- Storage Temperature: -20° ~ 60°C (-4° ~ 140°F)
- Operating Temperature: 0° ~ 50°C (32° ~ 122°F)
- 7" 800 x 480 TFT LCD, LED Backlight
- Slim design
- Fan-less cooling system
- COM1 and COM3 RS-485 dual isolation design ensures reliable operation in comlex grounding application
- COM1 and COM3 RS-485 2W support MPI 187.5K, please use one at one time
- PCB coating process ensures high reliability to resist from corrosive in harsh environment
- NEMA4 / IP65 compliant front panel
