50103
$485.57
GIMA 400 MULTIFUNCTION 5AMP 110V W/MODBUS
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Simpson Electric has been manufacturing analog and digital panel meters, as well as test instruments and equipment, since 1927.
They are well known for their 260 volt-ohm-millimeter and remain proudly made in the USA.
Series Features Include:
- System: 3-phase, 3 or 4 wire unbalanced load
- Voltage: 120/208, 120/240, 277/480, 63/110
- Measurement Range: 20% to 120%
- Current: 5 amp from external CTs Fully Isolated
- Measurement Range: 5% to 120%
- Operating Frequency: 45 to 65 Hz
- Harmonics: Up to the 30th harmonic
- Input Loading Voltage: Less than 0.1VA per phase
- Input Loading Current: Less than 0.1VA per phase
- Overload Voltage: x2 for 2 seconds max.
- Overload Current: x40 for .5 second max.
- Auxiliary Supply Standard: 115V±15% 45-65Hz
- Auxiliary Supply Optional: 230V±15% 45-65Hz
- Display: Custom backlit supertwist LCD 3 lines of .47”
- General: (12mm) digits plus .15” (3.8mm) legends
- Bezel: 3.79” x 3.79” (w/ .29” lip)
- Depth: 3.35”
- Panel Cutout: 3.62” x 3.62”
Technical Information:
