FRN800G1S-4U

FRN800G1S-4U

Alt: FRENIC-Mega Series

$45,923.12

VFD, 800hp, 460V, 3 Phase, For Constant and Variable Torque Apps

Weight:
982.80 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description



FRENIC-Mega is a high performance, multifunctional drive with the following control methods; PG vector control, sensorless vector control, dynamic torque vector control, PG closed-loop control and V/f control.

RS-485 communication is standard along with a RJ-45 connection port.

Two types of keypads are available:

  • TP-G1W-J1; Multifunction keypad
  • TP-E1U (Optional): Keypad with USB port
Specifications
Horsepower 800 hp
Housing/Enclosure IP00 (NEMA 1 Kit Optional)
Input Phase 3 Phase
Input Voltage 400-480V, 3 Phase
Outdoor Rated No
Output 3 Phase Output
Series FRENIC-Mega
Options Enclosed, Heatsink thru Back
STO (Safe Torque Off) No
Torque Load Constant/Variable (CT/VT)
Drives - Type of Drive High Performance
Warranty 3 Years
Alternate Part Number FRENIC-Mega Series
Weight 982.8

Series Features Include:

Control Inputs/Outputs:

  • Qty 9 digital inputs
  • Qty 2 safety inputs (dedicated)
  • Qty 3 analog inputs
  • Qty 6 digital outputs; Qty 2 relays (1 Form C & 1 Form A) & Qty 4 transistor, 56 selectable functions
  • Qty 2 analog outputs; selectable type; 0 to 10VDC or 4 to 20mA configurable to provide output signal proportional to 15 different functions
  • Qty 2 RS-485 connections
  • RJ45 keypad port & control terminal block connections
  • 24VDC output terminal rated 100mA
  • High Performance LED & LCD keypad with NEMA/UL type approved

Motor Control:

  • LD (Low Duty): 120% for 1 Min
  • MD (Medium Duty): 150% for 1 Min
  • HD (High Duty): 200% for 3s / 150% for 1 Min
  • High performance closed loop vector control with option card
  • High performance sensor-less vector control
  • Built-in braking transistor up to 40HP(LD)/30HP(HD)
  • Built in braking resistor up to 15HP(LD)/10HP(HD)
  • Single phase input for all models

Safety and Standard:

  • Safety input compliant with EN ISO13849-1, EN954-1, Category 3
  • UL508C, CE
  • UL Premium Rating
  • NEMA/UL Type 1 by Option Kit
